Google Nest Thermostat and APS Bundle

HVAC Compatibility

The Nest Thermostat works with most 24V heating and cooling systems, including furnaces, air conditioners, boilers, and heat pumps with either forced air or radiant delivery.
Heating and Cooling: 1 stage of heating (W1) and cooling (Y1) and a second stage of either heating (W2) or cooling (Y2).
Heat pump: with auxiliary or emergency heat (O/B, AUX)
Fan: (G)
Power: (C, Rh or Rc)
Some systems, including heating-only, cooling-only, zone-controlled, and heat pump systems, require a C wire or the Nest Power Connector.

Installation

Installation usually takes 30 minutes or less. Control it remotely with the Google Home app, or swipe on the side of the thermostat. Get the Trim Kit (sold separately) to keep your wall looking clean. Professional installation is strongly recommended for dual fuel systems.

Powering method

2x AAA 1.5V alkaline batteries

Colors

Charcoal
Fog
Sand
Snow

Certification

UL 60730-1, Automatic Electrical Controls for Household and Similar Use
UL 60730-2-9, Particular Requirements for Temperature Sensing Controls
ENERGY STAR® Certified

Connectivity and security

Voltage: 20-30VAC

Temperature range

Temperature. 32° to 104°F (0° to 40°C)
Humidity. Up to 90% RH unpackaged.
Pressure. Up to 10,000 ft altitude.

Humidity range

Display: 20% to 90% RH
Sensitivity: +/- 5% RH
Operating: 5% to 95% RH (non-condensing)

Power consumption

Less than 1 kWh/month

Bandwidth

50 MB/week upload and 50 MB/week download

Storage

Ambient:
Temperature
-4° to 113°F (-20° to 45°C)
Humidity
Up to 80%RH in packaging
Pressure
Up to 15,000 ft altitude

If you have the original Next packaging, store your thermostat in there. Our packaging is specifically designed to maintain the integrity of the load as well as keeping it dry, cool, and undisturbed.
Avoid moisture, it's a big enemy of any electronic device. If you have any old silica packets, they could greatly help preserve the longevity of your device.

What’s in the box

Nest Thermostat display
Nest Thermostat base
Mounting screws and wire labels
AAA backup batteries
Quick start card
Welcome Guide

Compatibility Checker

Heating & Cooling System Alerts

If something doesn’t seem right, it can send an alert.

Display

2.4 in (6 cm) color LCD
240x320 resolution
Mirrored glass finish

Product dimensions

Mass: 4.9 oz (139 g)
Diameter: 3.3 in (8.4 cm)
Depth: 1.07 in (2.72 cm)

Sustainability

Contains no hazardous substances
RoHS compliant
REACH compliant
Recyclable packaging
EU Persistent Organic Materials (EU POP)
WEEE
CEC Title 20
CEC Title 24 Residential
Conflict Mineral Free
Prop 65
Perchlorate Free
Halogen Free
Plastic components made with 49% post-consumer recycled materials

Warranty

2-year warranty
5-year standard warranty for HVAC Pros

Features:

15-amp resettable circuit breaker

1,440 joules of surge protection

Consumes <1W at all times

3-ft. heavy-duty cord

Angled space-saver plug

Child protective outlet covers

Convenient and eco-friendly product packaging

Specifications

Voltage:  125 VAC, +/-1-%, 60 Hz

Power Rating:  15 Amp

Surge Protection:  1,875W, 1,440 Joules

VPR Rating:  700V (L-N), 900V (L-G), 800V (N-G)

Outlet:  NEMA 5-15R

Length:  5"

Width:  2"

Height:  14.7"

Weight:  1.05 lbs

Cord Length:  3 Foot

Warranty:  The Manufacturer guarantees to the original purchaser or recipient of this advanced power strip that it is free from defects in material and workmanship for five years from the date of purchase. Warranty is limited to repair or replacement of the advanced power strip. Advanced power strips being returned must included proof of purchase.
